EMHF 101 - Ansys HFSS Introduction Training

Beginner Level Training - 1 day (8 hours)

About Ansys HFSS Introduction Training by CADIT

Introduction to Ansys HFSS 3D electromagnetic simulation for antennas, RF/microwave circuits, and high-speed interconnects. Covers model setup, materials, boundary conditions, excitations, meshing, frequency sweeps, S-parameters, and field visualization.

Perfect for RF, microwave, and high-speed design engineers.

Learning Outcomes

By the end of this training, you will be able to:
1. Navigate the Ansys Electronics Desktop (AEDT) interface
2. Set up, run, and analyze HFSS simulations
3. Understand HFSS FEM-based adaptive meshing
4. Distinguish between lumped and wave ports
5. Define simulation space and boundaries
6. Build simple 3D models in AEDT
7. Perform and plot a basic parameter sweep

Course Content

1. Introduction
   - Overview of Ansys & Ansys Electronics Desktop (AEDT)
   - Introduction to HFSS and Finite Element Method (FEM)
   2. Core Concepts & Simulation Setup
   - Boundaries & Simulation Space
   - Solution Setup
   - Lumped vs. Wave Ports
   - Parameterized Geometry
   - HPC and Optimetrics Basics
   3. Hands-On Workshops
   - Coaxially-fed Band Pass Filter
   - Patch Antenna with Open Region
   - Boundary
   - SMA-Microstrip Stub Simulation
   - Patch Antenna: S-Parameters & Fields
   - Microstrip Bend Geometry & Port Setup
   - Parameter Sweep Analysis
   4. Post-Processing & Results
   - S-parameters, field plots, and performance metrics

Related Ansys Products

• Ansys HFSS: High Frequency EM Simulation Software
• Ansys Electronics Desktop: Electronics Simulation
• Ansys Electronics Enterprise: EM Simulation Suite

Related Ansys Courses

• EMHF 102 - Ansys SIwave Introduction Training
• EMHF 201 - Ansys HFSS EMI/EMC Simulation (CISPR 25) Training
• EMHF 202 - Ansys HFSS SBR+ Antenna Placement & Performance Training
• EMHF 203 - Ansys SIwave Advanced Signal & Power Integrity Training
• EMHF 204 - Ansys HFSS 3D Layout & GDS Import Workflow Training

See all CADIT training courses

HRDCorp Claimable Ansys HFSS course

Certificate of completion provided. If based in Malaysia, this course can be reimbursed with the HRDCorp Program through our certified trainers.
